Enduro JM205110 - TJM205110 - Tapered Roller Bearing - Direct Timken Replacement - Top Side - AAxis Distributors

Enduro JM205110

$10.00

DIRECT TIMKEN REPLACEMENT
TAPERED ROLLER BEARING
JM205149 / JM205110
AAXIS#: TJM205110

Dimensions	INCH	MM
OD (D)	3.5433	89.9998
ID (d)	1.9685	49.9999
Width (T)	1.1020	27.9908

The Enduro JM205110 outer race cup joins with the Enduro JM205159 inner race cone (sold separately) to form a single tapered roller bearing suitable for applications that support both radial and axial loads.

4 in stock

SKU: TJM205110 Categories: Bearings, Roller Bearings, Tapered Tags: 3918791, 4019398, 7K8876, ALLIS-CHALMERS, B 1.1024 in, B 28.0009 mm, C 0.9055 in, C 22.9997 mm, CATERPILLAR, Cor 153908 N, Cor 34600 lbf, Cr 146791 N, Cr 33000 lbf, d 1.9685 in, D 3.5433 in, d 50 mm, D 89.9998 mm, D100223, D92240, Direct Timken Replacement, Enduro, GALION, GM, JM205110, JM205149, P12601E, r 0.10 in, R 0.12 in, r 2.54 mm, R 3.05 mm, Roller Bearing, Single Cone, Single Row, SKF, T 1.1020 in, T 27.9908 mm, Tapered, Timken, TWLM0001, VOLVO, WLM140001

Product Information

Enduro JM205110

JM205149 / JM205110

The Enduro JM205110 outer race cup joins with the Enduro JM205159 inner race cone(sold separately) to form a single tapered roller bearing suitable for applications that support both radial and axial loads. Made of high-alloy steel, the single cone is durable, heat tolerant, and resistant to contortion under heavy loads. The rollers are prevented from coming into contact with each other during use because of the stamped steel cage. This reduces friction, vibration, and noise. Because the tapered bearing unit is separable, the single cone assembly allows for lubrication and accurate adjustments.

Dimensions	INCH	MM	Load Rating	LBF	N
OD (D)	3.5433	89.9998	Cor	34600	153908
ID (d)	1.9685	49.9999	Cr	33000	146791
Width (T)	1.1020	27.9908
B	1.1024	28.0009	Limiting Speeds	RPM
C	0.9055	22.9997	Grease	4100
R	0.12	3.05	Oil	5400
r	0.10	2.54

Click Here to see the Reference Diagram.

Dimension	Description	Load Rating
OD (D)	Outside Diameter	Cr	Dynamic Load Rating
ID (d)	Inside Diameter	Cor	Static Load Rating
Width (T)	Bearing Width
B	Cone Width
C	Cup Width
R	Cone Radius
r	Cup Radius

Specifications

Weight	0.06875 lbs
Dimensions	4.5 × 4.5 × 1 in
A	""link"":""post""}
Access Restriction	""link"":""none""}
Actuator Type	bgcolor"":""""}"
Category	Bearings
Type	Tapered Roller Bearing
Item Shape	Single Row, Single Cone
Brand Name	Enduro
Part Number	JM205110, JM205110
Material	Steel
Outside Diameter (D)	3.5433 in, 89.9998 mm
Inside Diameter (d)	1.9685 in, 49.9999 mm
Width (T)	1.1024 in, 89.9998 mm
Load Capacity, Dynamic (Cr)	34,600 lbf, 153,908 N
Limiting Speed, Grease	4,100 rpm
Limiting Speed, Oil	5,400 rpm
Load Capacity, Static (Cor)	33,000 lbf, 146,791 N
